Kubota KX030-4 Compact Excavator
🛡️30-Day GuaranteeRefund or Exchange🚜24.7 HP Diesel PowerKubota V1505 Engine🚚Free Freight ShippingHeavy-Equipment Delivery
Commercial Digging Strength in a Compact 3-Ton Platform
The Kubota KX030-4 combines reliable diesel power, responsive hydraulics, strong breakout performance, and compact dimensions for productive work in restricted areas. Its Kubota V1505 diesel engine, two-speed travel system, auxiliary hydraulic circuit, and offset boom make it well suited to trenching, foundations, landscaping, utility installation, grading, and property maintenance.
Key Highlights & Capabilities
Kubota V1505 Diesel Engine: Produces 24.7 gross HP and 23.7 net HP at 2,250 RPM for dependable commercial performance.
7,330-Lb Breakout Force: Strong bucket force supports excavation in compacted soil, clay, gravel, and demanding ground conditions.
High-Flow Auxiliary Hydraulics: Provides up to 49.5 L/min for compatible breakers, augers, compactors, grapples, and other powered attachments.
Two-Speed Travel: Select 1.7 mph for controlled high-traction movement or 2.7 mph for efficient travel across the jobsite.
Offset Boom: Swings 76° left and 57° right for excavation alongside foundations, walls, fences, and road edges.
Compact 59-Inch Width: The 1,500 mm machine profile supports access to residential, commercial, and urban work areas.
Heavy-Duty Rubber Tracks: Provide traction and stability while reducing potential damage to pavement, driveways, and finished surfaces.
Hydraulic Dozer Blade: Supports backfilling, rough grading, leveling, cleanup, and machine stabilization.
ROPS/FOPS Operator Protection: Available canopy or cab configurations provide a protected, professional operating environment.
Large Fluid Capacities: A 48-liter fuel tank and 52-liter hydraulic system support productive working periods between service stops.
Technical Specifications
Specification | Details |
Model | KX030-4 |
Equipment Class | 3-Ton Compact Excavator |
Operating Weight | 3,140 kg (6,924 lbs) |
Engine | Kubota V1505-E4-BH-3USA Diesel |
Gross Engine Output | 24.7 HP (18.4 kW) at 2,250 RPM |
Net Engine Output | 23.7 HP (17.7 kW) at 2,250 RPM |
Overall Length | 4,600 mm (15 ft 1.1 in) |
Overall Width | 1,500 mm (4 ft 11 in) |
Overall Height | 2,420 mm (7 ft 11 in) |
Minimum Ground Clearance | 295 mm (11.6 in) |
Maximum Breakout Force | 3,325 kgf (7,330 lbs) |
Hydraulic Pump Capacity | 31.5 L/min × 2 plus 18 L/min × 1 |
Auxiliary Hydraulic Flow | 49.5 L/min (13.1 GPM) |
Maximum Traction Force | 2,845–2,915 kgf (6,272–6,426 lbs) |
Travel Speed | 2.7 / 4.3 km/h (1.7 / 2.7 mph) |
Swing Speed | 9.2 RPM |
Boom Swing | 76° Left / 57° Right |
Crawler Length | 1,980 mm (6 ft 5.9 in) |
Tumbler Distance | 1,560 mm (5 ft 1.4 in) |
Track Shoe Width | 300 mm (11.8 in) |
Track Type | Rubber |
Blade Width | 1,500 mm (4 ft 11 in) |
Blade Lift / Drop | +300 mm / −352 mm |
Fuel Tank Capacity | 48 L (12.7 gal) |
Hydraulic Oil Reservoir | 33.9 L (9 gal) |
Hydraulic System Capacity | 52 L (13.7 gal) |
Recommended Applications
Utility, irrigation, drainage, and foundation trenching
Residential and commercial landscaping
Roadside, fence-line, and confined-area excavation
Grading, backfilling, leveling, and site cleanup
Farm, estate, and property maintenance
Compatible hydraulic breaker, auger, grapple, and compactor work
Configuration notice: Operating weight, included equipment, and dimensions may vary according to cab, canopy, bucket, attachment, and factory configuration. Confirm the delivered machine specifications before operation.30 Day Guarantee+This product includes a 30-day refund or exchange guarantee beginning on the delivery date. Contact our support team within the eligibility period for claim instructions and return authorization.Shipping+
