AGT SE17SR 1.8-Ton Kubota D902 Diesel Mini Excavator
🛡️30-Day GuaranteeRefund or Exchange🚜Kubota D902 Diesel16 HP Tier 4 Performance🚚Free Freight ShippingAvailable in Eligible Areas
Premium Compact Excavation with Expandable Stability
The AGT SE17SR is a professional 1.8-ton mini excavator powered by a Kubota D902 three-cylinder Tier 4 diesel engine. Its expandable rubber-track undercarriage, enclosed ROPS cab, swing boom, quick-attach system, auxiliary hydraulics, and two-speed travel make it a versatile solution for construction, landscaping, utility work, trenching, agriculture, drainage, and property maintenance.
Key Highlights & Capabilities
Kubota D902 Diesel Engine: Three-cylinder Tier 4 powerplant producing 11.8 kW or approximately 16 HP at 2,300 rpm.
Expandable Undercarriage: Adjusts from approximately 990 to 1,300 mm for narrow access and greater working stability.
Enclosed ROPS Cab: Provides operator protection and a more comfortable working environment in changing conditions.
Swing Boom: Enables offset excavation beside structures, fences, foundations, and landscaping.
Quick-Attach System: Supports faster changes between compatible buckets and work tools.
Two-Speed Travel: Offers controlled low-speed maneuvering and faster movement across the jobsite.
Auxiliary Hydraulics: Provides hydraulic power for compatible attachments and specialized applications.
Engine Monitoring System: Provides operating information and alerts to help reduce downtime and support routine maintenance.
Technical Specifications
Specification | Details |
Model | AGT-SE17SR |
Machine Type | Crawler Mini Excavator |
Operating Weight | 1,800 kg / approximately 3,968 lb |
Engine | Kubota D902, three-cylinder Tier 4 diesel |
Power Output | 11.8 kW / 16 HP at 2,300 rpm |
Emissions Compliance | EPA Tier 4 Final / Euro V |
Overall Length | 3,575 mm / 140.7 in |
Track Width Range | 990–1,300 mm / 39–51.2 in |
Overall Cab Height | 2,405 mm / 94.7 in |
Transport Ground Length | 2,440 mm / 96.1 in |
Minimum Ground Clearance | 145 mm / 5.7 in |
Counterweight Clearance | 460 mm / 18.1 in |
Tail Turning Radius | 650 mm / 25.6 in |
Track Length | 1,593 mm / 62.7 in |
Track Gauge | 760–1,070 mm / 29.9–42.1 in |
Track Shoe Width | 230 mm / 9.1 in |
Maximum Digging Depth | 2,270 mm / 89.4 in |
Maximum Vertical Digging Depth | 1,910 mm / 75.2 in |
Maximum Digging Height | 3,535 mm / 139.2 in |
Maximum Dumping Height | 2,445 mm / 96.3 in |
Maximum Digging Radius | 3,910 mm / 154 in |
Ground-Level Digging Reach | 3,845 mm / 151.4 in |
Blade Lifting Height | 280 mm / 11 in |
Blade Digging Depth | 190 mm / 7.5 in |
Standard Features | Enclosed ROPS cab, swing boom, quick attach, expandable tracks, two-speed travel, auxiliary hydraulics, pilot controls, dozer blade, and engine monitoring |
Attachment compatibility: Confirm pin dimensions, mounting width, hydraulic flow, operating pressure, and quick-attach compatibility before purchasing additional work tools. 30 Day Guarantee+This product includes a 30-day return or refund guarantee. Contact our support team within 30 days of delivery to submit an eligible refund or exchange request.Shipping+
